Custom TREK 21.5 Inch Intel All-in-One POS Touchscreen Computer

Custom TREK 21.5 Inch All-in-One POS Touchscreen Computer
  • 15.6" Projected Capacitive Touch Screen
  • High Performance
  • Extreme Versatility
  • Extensive OS Support
  • Elegantly Functional
  • Rich Connectivity
  • 3 Year Warranty

Custom TREK 21.5 Inch All-in-One POS Touchscreen Computer

Custom TREK 21.5 Inch Intel All-in-One POS Touchscreen Computer

TREK by Custom Group is your versatile, all-in-one solution for true functionality. Designed to seamlessly power a variety of applications - including POS, Self-Service, KDS, Price Checker, and more - TREK combines performance, connectivity, and versatility to meet the demands of any customer touchpoint.

Packed with power and connectivity, the TREK Intel 21.5" offers a wide-range of possibilities. Pair it with Custom’s CONNECT stand for an instant self-service station. Retail-hardened and backed by Custom’s trusted warranty support, TREK is purpose-built to withstand the rigors of high-traffic, high-demand environments.

  • Specifications
  • Overview
  • Accessories
  • Support
Model Custom TREK 21.5 Inch Intel All-in-One POS Touchscreen Computer
Touch Display 21.5"
Resolution 1920 x 1080
Touch Technology True-Flat PCAP multi-touch
Brightness LCD Panel: 350 NITS | PCAP Touch: 310 NITS
Stand Optional
Processor Intel® Processor N97        Intel® Core i3-N305
RAM 8 GB - 16 GB LPDDR4
SSD 128 GB - 256 GB UFS 2.1
OS SUported Windows 10 IoT, Windows 11 Pro, Windows 11 IoT, Google ChromeOS Flex, Linux
USB Type-A 2x USB-A 3.0, 2x USB-A 2.0
USB Type-C 1x USB3.0 full-functioned (DP / PD 5 V / 2 A, 12 V / 1 A)
Micro USB 3x (accessory mounting)
CuDP 1x proprietary miniDP (for 2nd display)
 Serial Port 1x RJ48 (Powered RS232) (default: 0 V; optional support for 5 V, 12 V)
LAN 1x RJ45
Cash Drawer 1x RJ11
DC Jack 1x 2pin
Wireless LAN + BT WiFi6 + BT5.2 (optional)
Speaker 1x 3 W
NFC Via optional accessory
Power Supply 65 W / 12 V
VESA Mount 75 x 75 mm
Accessory Options 11.6" Non-Touch CFD, 2D Scanner, Camera / Microphone, Fingerprint Reader, iButton, LCM, Light Bar, MSR, Stand
Operating Temperature 0° C ~ 35° C (32° F ~ 95° F)
Storage Temperature -20° C ~ 60° C (-4° F ~ 140° F)
Humidity 20% ~ 80% RH non-condensing
Dimensions Without Stand: 571.8 mm (W) x 42 mm (D) x 309.6 mm (H) | With Stand: 517.8 mm (W) x 165 mm (D) x 334.5 mm (H
Weight 3.09 kg (without stand) | 3.95 kg (with stand)

TREK by Custom Group is your versatile, all-in-one solution for true functionality. Designed to seamlessly power a variety of applications - including POS, Self-Service, KDS, Price Checker, and more - TREK combines performance, connectivity, and versatility to meet the demands of any customer touchpoint.

Packed with power and connectivity, the TREK Intel 21.5" offers a wide-range of possibilities. Pair it with Custom’s CONNECT stand for an instant self-service station. Retail-hardened and backed by Custom’s trusted warranty support, TREK is purpose-built to withstand the rigors of high-traffic, high-demand environments.

Part Number Description
932PW010300M33 Trek 11.6-inch customer facing touch display, embedded NFC
932PW010400M33 Trek 11.6-inch customer facing display
932PW010500M33 LCM 2-Line Customer Display for Trek
938PW010100001 Fingerprint reader accessory for Trek Terminal
938PW010100002 2D scanner accessory for Trek Terminal
938PW010100003 3 Track MSR accessory for Trek Terminal
938PW010100004 NFC/RFID reader accessory for Trek Terminal
938PW010100005 LED Light Bar accessory for Trek Terminal
938PW010100006 Camera / microphone accessory for Trek Terminal
938PW010100007 Trek series POS stand for all screen sizes, 11.6", 15.6", 21.5"
938PW010100008 Trek USB Type-C Alt mode USB cable 2 meters / 6 feet
938PW010100009 Trek USB Type-C Alt mode USB cable 0.8 meters / 2.5 feet
938PW010100010 Trek 11.6" CFD Rear Facing Adjustable Mounting Arm
938PW010100011 65W 5mm Power Adapter: Trek Intel, Android, Monitor, and CFD
938PW010100012 iButton reader accessory for Trek Terminal

Custom America TREK Intel 21.5" Product Brochure
