Bluebird EF550R Rugged Handheld Computer

Bluebird EF550R Rugged Handheld Computer
  • Ultimate Full Touch Performance
  • The Largest Display
  • Faster, Wider BUT Less Power
  • Ultimate Rugged & Durability
  • Power every mminute of the workday
  • Enhanced Data Capture
  • Business Optimized Solution

Bluebird EF550R Rugged Handheld Computer

Bluebird EF550R Handheld Rugged Computer

Building on the success of Bluebird EF series, the all-new Bluebird EF550R handheld computer offers the larger display of 5.5” with full rugged, enhanced innovative features and form factor that provide more huge value and productivity to enterprise front line user environment.

  • Specifications
  • Overview
  • Accessories
  • Support
Model Bluebird EF550R Handheld Rugged Computer
Dimensions 166.45 x 85 x 18.6 mm
Weight 332g
Display 5.5” HD+ (1440 x 720), TFT-IPS
OS Android 10; upgradeable to Android 14
Android 11
CPU 2.2 GHz Octa Core Processor (SD660)
Memory 4GB RAM / 32GB UFS Flash
4GB RAM / 64 or 128GB Flash (Optional)
Communication [WIRELESS LAN]
WiFi: IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w;
Wi-Fi™ certified;
IPv4, IPv6, 2x2 MU-MIMO
WWAN: IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w;
Wi-Fi™ certified;
IPv4, IPv6, 5GHz 2x2 MU-MIMO

[WIRELESS PAN]
Bluetooth: Bluetooth v5.0, BLE Class 2
Data Capture 1D&2D image
Camera :
Rear – 13 MP autofocus; f/2.0 aperture; flash LED, PDAF
Front – 5 MP fixed focus 2.0

NFC :
ISO 14443 Type A and B;
FeliCa, Mifare and ISO 15693 cards;
P2P mode and Card Emulation via Host.
and UICC
Battery User Replaceable Standard Battery,
Li-Polymer 3.85V / 4350 mAh, 16.7Wh
User Replaceable Extended Battery,
Li-Polymer 3.85V / 6160 mAh, 23.71Wh
BOS™ PowerManager Station
Drop Spec Multiple 8 ft./2.4 m drop to concrete per MIL-STD 810G
Tumble Spec 2000 3.2 ft./1.0 m tumbles;
meets or exceeds IEC tumble specifications

The Largest-in-class Display

The largest-in-class 5.85-inch touch surface (5.5-inch display) provides more quality information to the device users and at the same time, it enhances working condition with the best-in-class outdoor readability for users to read the screen even in bright sunlight.

Ultimate Rugged & Durability

Through Bluebird TankSmith® technology, EF550R is designed for the enterprise with the highest-in-class drop spec of 6 ft. (1.82m) and sealing up to IP68 to provide the ultimate durability and usability allowing use in environments exposed to water, humidity, or dust.

Faster, Wider Network BUT Less Power

EF550R has 2x2 Multiple-User Multiple Input Multiple Output (MU-MIMO) technology that makes possible for multiple devices communicate with access points simultaneously through pinpoint beamforming, which leads to enhancement in Wi-Fi network speed, range, and capacity. And access point is the one who processes not the device, increasing device battery cycle time.

High-Capacity Smart Battery, Power for Hours

No need to worry about recharging while working! EF550R battery offers long working time during Internet browsing. Safe as it is a hard-pack and stable battery operation with support of BOS™ PowerManager. Hot Swap mode is available without running any application, ensuring task continuity without turning off the device or an application.

Enterprise Mobile Device Software Ecosystem BOS

Bluebird BOS™ (Business Optimizing Solutions) provides various features optimized for use of enterprise device from app development, device deployment, to business performance management as an integrated solution system. With BOS™ you can implement integrated management for EF550R in an efficient way.

Accessory Part #
1 Slot Cradle
4 Slot Cradle
Battery Toaster
Vehicle Mounting Cradle
Shoulder Strap
Shared Holster
Wearable Arm Mount
Handstrap

Bluebird EF550R Product Data Sheet
